Home
>
Accessories
>
Tubing Accessories
>
Tubing Sleeves
>
M113A016
Sleeve, 1/8" OD Tubing, for use with barbed fittings, bag of 10
Alternative Views:
Same day shipping for this item!
List Price ea. Bag of 10
$
8.50
Quantity in Stock:135
Product Code:
MSLA02
Qty:
Description
Specifications
Tubing Sleeve, Brass; for 1/8"OD Polyurethane tubing used with barbed fittings.
Model - M113A016 (Bag of 10)
Technical Data
Temperature Range
Use when temperatures consistently exceed 80
o
F (26
o
C)
Working Pressure
Use when pressures consistently exceed 70 PSI (4.8 b)
Weight
.1 oz. (2.83g) bag of 10
Materials
Sleeve
Brass
Model - M113A016
Bag of 10
DESCRIPTION
Model - M113A016
Features
Installation
Easily slides over barbed connection using fingers
Temperature / Pressure
Keeps the tubing secure to the barb when high temperatures or high pressure are expected
Material
Brass for corrosion resistance
