M566Z005
M566Z005
Drum Assembly and Program Pins for the CSP24 drum programmers; 2011 -T3 Aluminum Clear Anodized to (MIL-A-8625 Type 11). 316 Stainless Steel Shaft

Alternative Views:


Same day shipping for this item!
List Price $765.12

Quantity in Stock:6
Product Code: MDRM24
Qty:

Description Specifications 3D Viewer/CAD

Drum Assembly and Program Pins for the CSP24 drum programmers; 2011 -T3 Aluminum Clear Anodized to (MIL-A-8625 Type 11). 316 Stainless Steel Shaft
DESCRIPTION
Model - M566Z005




Features
Pins
Arrives complete with 300 each programming pins
Steps
24 steps by 24 positions
Bearings
Oilite Sintered Bronze Sleeve Bearing
Body
2011T3 Aluminum bar stock clear anodized to (MIL-A-8625 Type 11)
Anodized for offshore applications.
Longevity
10 million cycles
Installation
Easily slides in and out for quick program changes
Stops
Mechanical roll pin stops pre-installed
