CTV10O1
CTV10O1
Pneumatic Timer, 5/2 way valve, (1 - 15) second timing range

Alternative Views:


Same day shipping for this item!
List Price $568.90

Quantity in Stock:1
Product Code: CTV03

Seals

Seal type:
Viton [Add $3.00]

Qty:
Description Specifications

Pneumatic Timer Valve, Block Bleed with integrated 5/2 way valve; 1/8 NPT ports; 30% glass filled Noryl composite body with anodized aluminum base; Stainless Steel Components
DESCRIPTION
    Model - CTV10O1




Features


Connectivity
Used for pneumatic timing sequencing.  Supply air and the timing signal are kept separate, allowing freedom of the 5/2 way valve to use an independent regulated air pressure

Resolution
Repeat accuracy within .25 of 1% of the set point


Adjuster
Screwdriver slot head with tamper proof cap

Noryl Resin
Suitable for applications requiring wide temperature swings or placement in harsh environments


Longevity
10 million cycles


Ports
1/8 NPT






Options



Seals

Viton
