Accessories
>
Volume Chambers
>
CVL312
Volume Chamber (accumulator); 31 cubic inch; 1/8 NPT ports; Stainless Steel
Alternative Views:
Same day shipping for this item!
List Price
$
97.39
Product Code:
CCVL04
Qty:
Description
Specifications
Volume Chamber (accumulator); 31 cubic inch; 1/8 NPT ports; Stainless Steel
Model - CVL312
Technical Data
Connection
1/8 NPT
Lubrication
None required
Medium
Compressed air; inert gasses
Operating Pressure
Vacuum to 200 PSIG (13.8)
Temperature
-35 F (-37) to 150 (66)
Weight
8.8 oz. (273.7g)
Materials
Valve body
Drawn and welded stainless steel
Operation
Pressurize / Vent
Model - CVL312
DESCRIPTION
Model - CVL312
Features
Mounting
Strap or close nipple mounting
Stainless Steel
Welded Stainless Steel suitable for wide temperature swings or placement in harsh environments
Ports
A single1/8 NPT port for high flow
